#include <iostream>
	#include <opencv2/opencv.hpp>
	#include <opencv2/core/core.hpp>
	#include <opencv2/highgui/highgui.hpp>
	#include <opencv2/imgproc/imgproc.hpp>
	#include <vector>

	using namespace std;
	using namespace cv;


	bool is_rect_in_range(Rect rect, Rect Range)
	{
		if (    rect.x >= Range.x && rect.y >= Range.y
			 && rect.x + rect.width <= Range.x + Range.width
			 && rect.y + rect.height <= Range.y + Range.height
		   )
			return true;

		return false;
	}

	bool is_rect_intersect(Rect rect, Rect Range)
	{
		Rect inter = rect & Range;
		if (inter.width > 0 && inter.height > 0)
			return true;

		return false;
	}

	int main(int argc, char **argv)
	{
		Mat img;

		int line_no = 0;
		if (argc >= 2)
			img = imread(argv[1]);
		else {
			cout << "Usage: ./cv_contours file" << endl;
			return -1;
		}

		if (argc == 3)
			line_no = atoi(argv[2]);


		Mat imgCopy(img);
		Mat imgCopy2(img.clone());
		//Mat imgCopy2(img);

		Mat imgGray;

		cvtColor(img, imgGray, COLOR_BGR2GRAY);

		//imshow("Gray", imgGray);

		Mat blurMat;

		blur(imgGray, blurMat, Size(3, 3));

		//imshow("blur", blurMat);


		Mat dstImage;


	//   Canny(blurMat, dstImage, 100, 200);
		//Canny(blurMat, dstImage, 50, 200);

	//   imshow("canny", dstImage);

		threshold(blurMat, dstImage, 192, 255, THRESH_BINARY);

		//imshow("thresh", dstImage);

		vector < vector < Point >> contours;

		Mat edges(dstImage);

		//findContours(edges, contours, RETR_EXTERNAL, CHAIN_APPROX_SIMPLE);
		//findContours(edges, contours, RETR_LIST, CHAIN_APPROX_SIMPLE);
		//findContours(edges, contours, RETR_CCOMP, CHAIN_APPROX_SIMPLE);
		findContours(edges, contours, RETR_TREE, CHAIN_APPROX_SIMPLE);
	//   findContours(edges, contours, RETR_TREE, CHAIN_APPROX_TC89_L1);
	//   findContours(edges, contours, RETR_TREE, CHAIN_APPROX_TC89_KCOS);

		std::cout << "There are " << contours.size() << " contours" << endl;

		Mat resizeImage;

		int obj_total = 0;

		vector < Rect > RectArray, simpleRectArray, intersectRectArray, unionRectArray;

		for (int i = 0; i < contours.size(); i++) {
			Rect rect = boundingRect(contours[i]);
			//if(rect.area() >= 25 && rect.width >=5    && rect.height >=5
			//                   && rect.width <= 200 && rect.height <= 200 ){
			if (1) {
				if (line_no) {
					if (rect.y >= line_no * 200 && rect.y <= (line_no * 200 + 400))
						;
					else
						continue;
				}

				if (rect.x <= 300 || (rect.x >= 2900 && rect.x <= 3550) || rect.x >= 5700)
					continue;

				if (rect.area() < 16)
					continue;
				if (rect.height <= 6)
					continue;
				if (rect.width > 400)
					continue;

				obj_total++;

				rectangle(imgCopy, rect, Scalar(0, 0, 255));
				// imshow("edges", imgCopy);

				RectArray.push_back(rect);

				// if(i % 100 == 0){
				//destroyAllWindows();
				//resize(imgCopy, resizeImage, Size(), 0.2, 0.2);
				//imshow("resize1", resizeImage);

				cout << "rect.width and height are: " << rect.width << " "
													  << rect.height << endl;
	#define ROI_RANGE  20
				int xl = MAX(0, rect.x - ROI_RANGE);
				int xr = MIN(imgCopy.cols, rect.x + rect.width + ROI_RANGE);
				int yt = MAX(0, rect.y - ROI_RANGE);
				int yb = MIN(imgCopy.rows, rect.y + rect.height + ROI_RANGE);
				Rect outter(xl, yt, xr - xl, yb - yt);

				Rect inner(rect.x + 1, rect.y + 1, rect.width - 2, rect.height - 2);
	//    rectangle(imgCopy, inner , Scalar(0, 255, 0));
	//    rectangle(imgCopy, outter, Scalar(0, 0, 255));


				//Rect roi(rect.x, rect.y, rect.width, rect.height);
				Rect roi(outter.x, outter.y, outter.width, outter.height);
				//Rect roi(rect.x-2, rect.y-2, rect.width+4, rect.height+4);

				//Mat roiImage =  imgCopy(roi);
				Mat roiImage = imgCopy(outter);
				cout << "roiImage.width and height are: " << roiImage.cols << " "
														  << roiImage.rows << endl;

				destroyAllWindows();
				namedWindow("roi", WINDOW_NORMAL);
				imshow("roi", roiImage);

				//if(i % 100 == 0)
				//    waitKey(0);
				//else
				//    waitKey(1000);
				cout << i << " second" << endl;
				//}


			}
		}


		cout << "Total " << obj_total << " objects counted\n" << endl;
		cout << "or Total " << RectArray.size() << " elements counted\n" << endl;



		for (int j = 0; j < RectArray.size(); j++) {
			bool is_inside = false;
			for (int i = 0; i < RectArray.size(); i++) {
				if (i == j)
					continue;
				if (is_rect_in_range(RectArray[j], RectArray[i])) {
					is_inside = true;
					break;
				}

			}
			if (!is_inside)//只选择最外部的矩形，那些包围在别的矩形内的矩形不选
				simpleRectArray.push_back(RectArray[j]);
		}

		//for(int i = 0; i < simpleRectArray.size(); i++){
		//    rectangle(imgCopy2, simpleRectArray[i], Scalar(255, 0, 0));
		//}

		cout << "simple Total " << simpleRectArray.size() << " elements counted\n" << endl;








		for (int j = 0; j < simpleRectArray.size(); j++) {
			bool is_intersect = false;
			for (int i = 0; i < simpleRectArray.size(); i++) {
				if (i == j)
					continue;
					//对于相交的矩形，
				if (is_rect_intersect(simpleRectArray[j], simpleRectArray[i])) {
					// is_intersect = true;
					//获取它们的并
					intersectRectArray.push_back((simpleRectArray[j] | simpleRectArray[i]));
					break;
				}

			}
		}

		//for(int i = 0; i < intersectRectArray.size(); i++){
		//rectangle(imgCopy2, intersectRectArray[i], Scalar(0, 255, 0));
		//}

		cout << "intersect Total " << intersectRectArray.size()
								   << " elements counted\n" << endl;


		for (int i = 0; i < intersectRectArray.size(); i++) {
			simpleRectArray.push_back(intersectRectArray[i]);//添加到已有的数组后部
		}
		cout << "simple + intersect Total " << simpleRectArray.size()
											<< " elements counted\n" << endl;
		for (int i = 0; i < simpleRectArray.size(); i++) {
			rectangle(imgCopy2, simpleRectArray[i], Scalar(255, 0, 0));
		}









		for (int i = 0; i < simpleRectArray.size(); i++) {


	#define EXTERNAL_RANGE   30
			Rect rectSearchRange(
								 simpleRectArray[i].x - EXTERNAL_RANGE,
								 simpleRectArray[i].y - EXTERNAL_RANGE,
								 simpleRectArray[i].width + 2 * EXTERNAL_RANGE,
								 simpleRectArray[i].height + 2 * EXTERNAL_RANGE
								);


			for (int j = 0; j < simpleRectArray.size(); j++) {
				if (j == i)
					continue;

				if (is_rect_intersect(simpleRectArray[j], rectSearchRange)) {
					//尝试生成一些矩形图像的并（不是所有的并都有意义，但以后我们可以从中手工选择）
					Rect union_rect = simpleRectArray[j] | simpleRectArray[i];
					if (union_rect.width <= 200 && union_rect.height <= 200) {
						unionRectArray.push_back(union_rect);
						rectangle(imgCopy2, union_rect, Scalar(0, 0, 255));
					}

				}
			}
		}
		cout << "union Total " << unionRectArray.size() << " elements counted\n" << endl;











		//resize(imgCopy, resizeImage, Size(), 0.2, 0.2);
		//imshow("resize", resizeImage);

	//   Rect roi_line(0, line_no*200, imgCopy.cols,400);
	//   Mat  roi_lineImage = imgCopy(roi_line);
		Rect roi_line(0, line_no * 200, imgCopy2.cols, 400);
		Mat roi_lineImage = imgCopy2(roi_line);
		destroyAllWindows();
		imshow("roi_line", roi_lineImage);



		waitKey(0);
		return 0;

		/*
		   int x = 200,y = 200, width = img.size().width-2*x, height = img.size().height-2*y;
		   cv::Rect roi(x,y, width, height);

		   cv::Mat roiImage =  img(roi);
		   bool isSaved = cv::imwrite("output.jpg", roiImage);
		   if(isSaved)
			   std::cout << "OK"   << std::endl;
		   else
			   std::cout << "fail" << std::endl;


		   imshow("LOVE", img);

		   waitKey(0);
		   return 0;
		*/
	}
